Enveloped actions. Dynamic oscillations. Bursts of energy. Capsulated audio.

Capable of generating complex envelopes, modulation signals and audio, wave packets allows you to sculpt your sound by producing time-limited signals or “wave packets”. Each wave packet is determined in the four primary dimensions of time, depth, frequency and wave shape. With five distinct unipolar and bipolar outputs, an infinite and unique range of shapes and sounds can be produced: an envelope growing from nothing to wild oscillation, a punchy bass drum with monstrous pitch decay, a ping-multiplied burst generator, an amplitude-varying LFO or timbre-morphing oscillator. The novel model combines frequency-dynamic oscillation and function generation for crafting modulation and audio signals that fuel creativity. A highly versatile production tool kit in 16HP.

Features:

• Ability to design novel control voltage shapes, or use as an audio source
• 5 simultaneously utilisable outputs with distinct models - 3 unipolar, 2 bipolar
• 24-bit wavetable audio oscillator, voltage-precise LFO
• Continuous wave shape morphing, including PWM and skewable exponential in to sawtooth
• Contour function drawn from 3 slider controls
• Traverses through 3 frequencies with glide control
• Colour-frequency representation LEDs
• 4 time stages, with LED indication, each adjustable between 0s (skip) to 10s, and optional sustain stage
• 'Linked' stage time mode which allows the ability to sync stage times to the oscillator period
• Ability to stretch and shrink the overall wave packet using V/OCT in linked mode
• Various excitation/ trigger options, including gated, trigger, cycle, pingable‑stages cycle, and free‑running modes
• Ping input frequency/ rate control, with multiplication/ division or offset controls
• EOS, EOC outputs
• Accurate 16-bit tracking V/OCT input, +-9V range. -V useful for general FM
• Depth and wave shape CV inputs, running at oversampled audio rates
