WAV Recorder

Out of stock
Product number: CV3075

High Fidelity, Low noise, Stereo Recorder

  • +12V 112mA
    -12V 12mA
    +5V 0mA
    Width 6HP
    Depth 25mm


High Fidelity, Low noise, Stereo Wav Recorder

• Up to 96kHz, 24-bit stereo recording.
• Configurable to 96kHz, 48kHz, or 44.1kHz; and 24-bit or 16-bit; stereo or mono
• Accepts modular signal level or line level.
• Gain knob and LED level meter allows you easily boost or cut any signal, from synths to smart phones, without clipping.
• Audio can be monitored without recording, so the WAV RECORDER can also be used as a pre-amp for boosting line-level signals to modular level.
• Playback previous recordings or standard WAV files on the microSD Card
• Playback and Record activated by button press, or a trigger jack
• Recording time and number of files are limited only by available space on card: Typical cards can hold hundreds of hours of samples.
• Continuous Recording feature automatically breaks long recordings (>6 hours, typically) into multiple 4GB files. With a large SD Card (128GB), you can literally record continuously for 2 weeks without stopping!
• Connects to the LISTEN modules for recording directly from the main output.
• 24-bit 96kHz Codec (DAC and ADC)
• Includes 16GB microSD card

In the Box
• The module itself
• Eurorack Power Cable, 16gb microSD card
