KOMA Elektronik

Radius 1U

$49.00
Available Immediately
Product number: CV5210



1U FM Radio

  • +12V 56mA
    -12V 2mA
    +5V 0mA
    Width 8HP
    Depth 23mm

Description

1U FM Radio

The FM RADIUS is a CV-tunable radio receiver capable of receiving radio broadcasts on the FM bands. It provides the user the ability to catch radio transmissions for further manipulation. Use it as a crazy oscillator, infinite sample generator or just listen to the news during your office break.

The CV Radio is capable of catching the strongest broadcasts without any external antennas but for better reception, an external antenna should be used.

  • CHAOS - Use this CV input to scan the FM band for radio signals.Provides
    CV control over the search potentiometer.
  • ANTENNA - Lets you connect an external antenna to improve the radio
    reception.
  • SEARCH - When there’s no signal connected to the Search input, the
    Search control functions as a manual CV source for tuning the radio. When a
    signal is connected to the Search input, the Search control acts as an atte-
    nuator for the incoming CV signal.
  • OUTPUT - Outputs the radio transmission caught with the FM Radio.
