The One 16 Voice

Out of stock
Product number: CV3146

Tri-timbral, Polyphonic, 16-Voice Analog Synth


Tri-timbral, Polyphonic, 16 Voice analog synth

Moog One is the ultimate Moog synthesizer - a tri-timbral, polyphonic, analog dream-synth designed to inspire imagination, stimulate creativity, and unlock portals to vast new realms of sonic potential. The first polyphonic analog synthesizer from Moog in more than three decades, Moog One is the culmination of years of research and has been developed to exceed every expectation of a polyphonic Moog instrument.

Available in 8-voice and 16-voice configurations, Moog One's polyphonic sound engine is built on the most powerful synthesizer architecture ever employed by a Moog instrument. Per voice, Moog One offers 3 newly-designed analog VCOs, 2 independent analog filters, a dual source analog noise generator, analog mixer with external audio input, 4 LFOs, and 3 envelopes. To deliver an infinitely inspiring performance experience, each of the three timbres can be easily split or layered across Moog One's expressive 61-note keyboard, each with its own sequencer, arpeggiator, and onboard effects library--including a a suite of professional reverbs from Eventide®.

Each Moog One voice employs three newly developed triangle core analog VCOs. The output of each oscillator is a user-defined mix of the selectable triangle / sawtooth wave, plus a variable-width pulse wave. Expanding beyond traditional oscillator designs, the rise/fall time of the triangle wave and the reset phase of the sawtooth wave can be shaped and modulated to create to a rich palette of classic analog tones. Blending the tri/saw and pulse waves together opens new dimensions of harmonic freedom, creating complex waveforms not typically found in analog synthesizers. The Moog One oscillator section is also equipped with hard sync, analog ring modulation, and FM for boundless analog sound generation.

• 16 voice polyphony, 3-part multi-timbrality
• 3 VCOs per voice with waveshape mixing and OLED displays
• Unison Mode (up to 48 Oscillators on a 16-voice instrument)
• 2 filters per voice with filter mixing (2x Multimode State Variable filters that function as a single filter, and a classic low pass / high pass Moog Ladder filter)
• 3 DAHDSR envelopes per voice with user-definable curves
• Sequencer and arpeggiator per timbre. Chord memory
• Dual source noise generator with dedicated envelope
• Mixer with external audio input
• Ring modulation with selectable routing
• Oscillator FM and Hard Sync with selectable routing
• 4 assignable LFOs
• Premium 61-note Fatar TP-8S with velocity and aftertouch
• Assignable pressure-sensing X/Y pad
• Digital Effects (Synth and Master Bus)
• Selectable glide types
• Save, categorize, and recall tens of thousands of presets
• Create performance sets to make up to 64 presets accessible at the push of a button
• 2x 1/4” headphone outputs
• 2x pairs of assignable 1/4” outputs (Support for TRS and TS connection)
• 4x 1/4” hardware inserts (TRS)
• 1x 1/4” external audio input (line level)
• 1x XLR + 1/4” TRS combo external audio input with trim knob
• 9x assignable CV/GATE IO (5x in / 4x out)
• USB drive support for system and preset backup
• LAN port for future expansion

Physical Specifications
• Weight: 45 lbs. / 20.4kg (approximate)
• Dimensions: (W x D x H) 42” x 20” x 7” / 107cm x 51cm x 18cm
